B&G B&G ZG100 GPS Antenna With Rate Compass

Dependable, precise positioning

The B&G ZG100 GPS Antenna provides precise and dependable position data making it the perfect partner for B&G chartplotters and instrument systems. The highly accurate 10 Hz GPS gives precise and smooth update of position information during acceleration and manoeuvring, rapid signal acquisition and consistent position accuracy augmented by secondary satellite systems like WAAS, EGNOS, MSAS and Galileo. It is also QZSS-ready.

The integrated compass delivers accurate heading information for instruments, chart stabilisation for Head Up mode and Radar overlays. It also provides Heel and Trim data for sailing.

B&G ZG100 GPS Antenna Features:

• Highly accurate position
• 10Hz update rate
• Sail Specific COG/SOG filtering for optimum performance
• GPS/Galileo support
• Augmented with WAAS, EGNOS and more
• Integrated heading sensor
• Heel and Trim sensors
• Compact, waterproof (IP67) design
• NMEA 2000

B&G ZG100 GPS Antenna Specifications:

• Model number: 000-11048-002
• Waterproof rating: IPX-7
• Diameter: 3.54in (90mm)
• Weight: 0.30lbs (0.14 kg)
• Compass safe distance: 21in (518mm)
• Operating temperature range: 13°F to 149°F (-25°C to 65°C)
• Storage temperature range: -22°F to 158°F (-30°C to 70°C)
• Dimensions: 3.54 x 1.5in (90 x 38mm)
• Warranty Period: 5 Years
• Supply voltage: 9v-18v
• NMEA 2000 Connectivity: Yes

What’s in the box:

• B&G ZG100 GPS Antenna
• NMEA 2000 6ft Network Extension Cable
• N2K-T-RD Network T-Connector

Note: This product is not suitable for use with MARPA or B&G Pilot systems; this requires a rate compass such as the Precision-9, RC42 or Halcyon Gyro-Stabilised Compass.
