HALO24 revolutionizes radar by presenting an almost real-time view, with industry-first 60 RPM operation at close range for the ultimate in collision avoidance. Detect hazards instantaneously with VelocityTrack Doppler technology, and enjoy simultaneous short and long-range coverage-up to 48 nautical miles-from one compact 24-inch dome antenna.

See Near and Far with One Compact Dome

Perfect for mid-sized to large sailboats, HALO24 comes in a compact dome antenna and offers high-quality short, mid and long-range detection. Display two ranges at once in B&G’s patented Dual Range mode, which enables you to keep an eye on far away weather cells, while watching for collision dangers up close. HALO24 radar’s pulse compression technology means no compromises in detection at either selected range, while beam sharpening provides enhanced separation between small or distant targets.

The Ultimate View for Collision Avoidance

HALO24 radar delivers a full 360 degree sweep every second, thanks to its industry-first 60 RPM rotation at ranges up to 1.5 nautical miles. These ultra-fast updates give you an almost real-time view at close range, offering the ultimate view for collision avoidance.

VelocityTrack Doppler Technology Built-In

VelocityTrack technology provides instant visual feedback on whether targets are coming towards you or moving away. Simple color coding highlights potential hazards, improving your situational awareness and further reducing your risk of collision. HALO24 radar automatically checks every target in range; there’s no need to manually select individual targets, and no limit to the number of targets on screen at one time.

Ready When You Are

HALO24 radar wakes instantly from its low-power standby mode, delivering this high-speed radar coverage exactly when and where you need it. Even if your HALO24 radar is completely powered down, start-up is a matter of seconds, not minutes like traditional pulse radar. Whether you’re navigating through crowded waterways or contending with poor visibility, HALO24 radar immediately cuts through the clutter to give you a clear and current picture of your surroundings.

The Lightest 24” Radar for Enhanced Performance

HALO24 lightweight compacted design -6.75kg, 14.9lb- minimizes the inclination of the yacht to maximize your boat’s performance when every second counts.

Features:

48 nm range from a compact 24-inch dome
The lightest 24” radar (6.75kg, 14.9lb)
Advanced pulse compression technology with beam sharpening
Simultaneous Dual Range operation sees both near and far
Ultra-fast 60 RPM operation at ranges up to 1.5 nm
VelocityTrack Doppler technology for collision avoidance
Easy operation with harbour, offshore, weather, and bird modes
MARPA target tracking (up to 10 targets, 20 in dual range)
Instantly awake from standby
Best in class weather and target detection

Specifications:

Specifications

Waterproofrating: IPX6
Supply Voltage: 10.5 – 31.2 VDC (12/24V systems)
Ethernet Ports: 100 Base T
Max Wind Speed: 100 knots (51 m/s)
Warranty Period: 2 Years
Power Consumption typical: 20W
Operating Temperature Range: -25 degrees to + 55 degreesC (-13 degrees to +130 degreesF)
Power Consumption max: 29W
Beam width: 3.9 degrees H nonminal (-3dB) 2 degrees with target separation on high x 22 degrees V
Max Range, scale: 48 NM
Min Range, scale: 50 m / 200 ft / 50 yd
Recommended Fuse Rating: 5A
Weight: 6.75 kg (14.9 lbs) without cable
Dimensions W x H x D: 610mm dia x 225 mm H. (24′ dia x 8.9′ H)
Humidity: 95% RH at 35 degreesC (95 degreesF)
Interface: BandG MFD
Approvals Compliance: FCC, Part 47 CFR 80 and 90: RED, Article 3 of Directive 99/5/EC: CE: EN, EN302-248 V2.1.1: Industry Canada, RSS238: RCM (C-Tick): IEC60945 Sec 9.2,9.3, 10.3-10.9, 11.2: IEC60950 Electrical Safety
Radar Modes: Harbour, Offshore, Weather, Bird Dual Range, North Up Course Up, Relative motion, True Motion
Radar Technology: Pulse Compression
Rotation speed: Up to 60 RPM (Range Dependent)
